Maksiwa Sliding Panel Saw 126" with Tilting Blade, Cabinet Saw - BMS.3200.IR

The BMS.3200.IR is a sliding panel table saw tailor made to provide high quality precise cuts in diverse angles with a max cut depth of 4 inches (100 mm) at 90º.

It includes a 5 HP motor, cutting guides, miter guide, blade guard. The noise level of this equipment is 76.5 dB (the machine turned on only) up to 110 dB (with the machine on and the exhaust system on.

The noise will vary in accordance with the location the machine is in and the materials used).

You can view the entire Maksiwa range, including Maksiwa edgebanders, all panel saws, and sliding panel saws. Also see our entire sliding panel saw range, mitter saws, rip saws, resaws, and band saw range.

FREE VIDEO INSTILLATION WALKTHROUGH INCLUDED .

Dimensions

• CUTTING CAPACITY
• A Manual adjustment cutting width: 48″
• B Crosscut fence closed: 71″
• C Crosscut fence extended: B + C + 59 = 130″
• D Sliding table lenght: 126″
• E Sliding table travel: 138″

Parts Function

1. MOBILE ARM
2. MOBILE TABLE SUPPORT
3. BLADE TILT CONTROL HANDLE
4. CONTROL PANEL
5. EMERGENCY BUTTONS/SWITCHES
6. MAIN TABLE LOCK
7. SLIDING TABLE HANDLE
8. ADJUSTABLE TABLE HANDLE
9. ADJUSTABLE ANGLE GUIDE
10. REAR EXTENSION TABLE
11. REAR EXTENSION TABLE GUIDE
12. PANEL PUSHING HANDLE
13. BLADE PROTECTOR COVER
14. DUST COLLECTOR PORT
15. SUPPORT TABLE
16. WOOD PANEL CLAMP
17. BLADE HEIGHT ADJUSTMENT HANDLE
18. SCORING BLADE ADJUSTMENT HANDLES
19. MEASURING TAPE METRIC & STANDARD
20. ALUMINIUM TABLE GUIDE
21. WOOD PANEL STOPPER
22. ALUMINIUM GUIDE EXTENSIONS

Parts Images

Adjustable Angle Guide

Adjustable Table Handle

Aluminum Guide Extensions

Aluminum Table Guide

Blade Tilt Control Handle

Control Panel

Dust Collection Ports

Emergency Buttons

Flip Stoppers

Main and Scoring Blades

Measuring Tape - Metric & Imperial

Mobile Table Support

Panel Pushing Handle

Rear Extension Table Guide

Rear Extension Table

Scoring Blade Adjustment

Scoring Blade Adjustment and Blade Up - Down Handle

Sliding Table Handle

Sliding Table Lock Positions

Sliding Table Lock

Support Table

Wood Panel Clamp

Wood Stopper

Specs

GENERAL

TECHNICAL INFORMATION	BMS.3200.IR
Weight	1,470 Lbs
Machine dimensions (closed)	L 133” x W 135” x H 65’’
Machine dimensions (max)	L 192” x W 280” x H 65’’
Sliding table dimension	14 3/4” X 132”
Sliding table max travel length	280”
Fixed table max width	52”
Guide size (closed)	71”
Guide size (max)	128’’
Blade cover	1 unit
Lockable main power switch	1 unit
Emergency buttons	2 units
Max tilt	45°
Max depth cut	3“
Max cutting length	120”
Warranty	2 Years

BLADE

TECHNICAL INFORMATION	BMS.3200.IR
Main blade diameter	12”
Main blade arbor size	1”
Scoring blade diameter	4 ¾’’
Scoring blade arbor size	25/32”

DUST COLLECTOR

TECHNICAL INFORMATION	BMS.3200.IR
Port 1 diameter	4’’
Port 2 diameter	3’’
Minimum CFM needed	600 CFM

ELECTRICAL OPTIONS

3 PHASE MODEL 380 V	BMS.3200.IR
Main motor	10 Amps – 5 HP
Main motor – Non-loaded blade speed	4,000 RPM
Scoring motor	1.5 Amps – 3/4 HP
Scoring motor – Non-loaded scoring blade speed	8,000 RPM

3 PHASE MODEL 220 V	BMS.3200.IR
Main motor	20 Amps – 5 HP
Main motor – Non-loaded blade speed	4,000 RPM
Scoring motor	2.5 Amps – 3/4 HP
Scoring motor – Non-loaded scoring blade speed	3,500 RPM

1 PHASE MODEL 220 V	BMS.3200.IR
Main motor	20 Amps – 5 HP
Main motor – Non-loaded blade speed	4,000 RPM
Scoring motor	2.5 Amps – 3/4 HP
Scoring motor – Non-loaded scoring blade speed	3,400 RPM

1 PHASE MODEL 110 V	BMS.3200.IR
Main motor	35 Amps – 5 HP
Main motor – Non-loaded blade speed	3,400 RPM
Scoring motor	5 Amps – 3/4 HP
Scoring motor – Non-loaded scoring blade speed	8,000 RPM
